Midcomp
Max Roll Width
1016mm/40-inch
Max Media thickness
10mm Board Thickness
Ink Cartridge Size
1L CMYK Inks
Max Sheet Size
1020mm Board Width
Max Print Speed
15m/hr Print Speed

Models in this series

  • HP PageWide XL 5200 40-in Multifunction Printer

    Scan resolution, optical
    1200 dpi
    Scanner maximum media thickness
    0.26 mm
    Weight
    412 kg
    Package weight
    541 kg
    Maximum copy length
    9.5 m
    Scan file format
    JPEG, TIFF, multi-TIFF, PDF, PDFA, multi-PDF, multi-PDFA (with PostScript/PDF upgrade)
    Scan input modes
    Printer storage, USB drive, network folder (SMB), My home folder, scan to email, scan to HP SmartStream software
    Scan size, maximum
    Up to 914 mm
  • HP PageWide XL 5200 40-in Printer

    Weight
    382 kg
    Package weight
    516 kg

Tell us which one you are pricing and we will quote that machine rather than the range.

HP PageWide XL 5200 – LEAD – Fast delivery times in monochrome and colour

Up to 14 x A1 pages/minute print speed & quick 30-second first page out. Deliver mixed monochrome and colour sets in 50% of the time with a consolidated workflow. Start printing in 50% of the time – an ultra-fast processor, native PDF management, HP SmartStream software. Free up the operator – production stacker/online folder, up to 4 rolls, dual ink supplies with auto-switch.

GROW – Fast colour, excellent document quality

Generate new business growth – print GIS maps, point-of-sale (POS) poster printing applications at breakthrough speeds. A poster printer like no other! Set a new technical document standard with crisp lines, fine detail & smooth grayscales that beat LED. HP PageWide XL pigment ink for dark blacks, vivid colours, moisture/fade resistance – even on uncoated bond. Print on a wide range of media up to 40 inches/1016mm – covering ISO/US technical & offset standards.

HP PageWide XL 5200 – SAVE – Cut total production costs up to 30%

The HP PageWide XL Pro 5200 can print monochrome & colour technical documents at the same or lower cost than comparable LED printers. Do it all with one space-saving device for both monochrome and colour, or opt for the MFP to print/scan/copy. Cut job preparation & finishing costs by up to 50% See up to 5 times lower energy consumption than comparable LED printers.

Specifications

Questions people ask

How fast is it, and how much ink does it hold?

Up to 1,016 mm (40 in) wide at up to 15 m a minute, from a 1-litre black and 500 ml colours. It is a production machine — the figure that matters is not the top speed but that it holds it on a long unattended queue, which is what the cartridge volumes are sized for.

How does it compare with an LED or toner plotter?

A PageWide XL lays down a full page width in one pass with a fixed printhead array, so the paper moves and the heads do not. Colour comes out at the same speed as mono, which on an LED or toner plotter it does not — colour there is the slow option, so drawings get printed in black to keep the queue moving. If your revisions, services and markups are colour-coded, this is the machine that lets you actually print them that way.

Do we need the multifunction version?

The multifunction version adds an integrated scanner, which matters if you copy marked-up drawings or archive signed prints. If drawings only ever leave the office as prints, the plain printer does the same printing for less. The scanner cannot be retrofitted later, so it is a decision made at purchase.

What is the difference between the 5200 and the 5200 MFP?

This page covers both — the 5200 printer and the 5200 multifunction printer with an integrated scanner — and they are listed separately above. The printing is identical. The Pro 5200 is the same speed again with larger cartridges and a production finisher.

Is the warranty really 90 days?

HP publishes 90 days on this machine, and that is the figure in the spec table because inventing a longer one would not make it true. Production machines in this class are bought with a service contract rather than on the base warranty — that is what sets the response time and what covers the printheads. Ask us what the contract looks like for your volume before comparing it against another manufacturer's headline warranty.

What does it cost to run?

It depends on what you print. Ink use moves with coverage, and media is the larger cost on most jobs and is bought separately whatever way the machine is financed. Rather than guess, tell us what you print in a normal month and we will work it out against your own volume. If you want one predictable figure instead of three variable ones, that is what Pay Per Use is for.

Can I see it print my own file before I commit?

Yes. Bring the file you are worried about to the Midcomp Innovation Hub in Ferndale and run it on the machine, on the substrate you actually use, and take the sample away. It is by appointment so the machine and a specialist are both free when you arrive.

What happens if it breaks down?

Midcomp services what it sells, from Johannesburg, Cape Town and Durban. If the machine is on Pay Per Use and it stops, its work can be run at the Innovation Hub while it is repaired, by arrangement — so a fault does not have to become a missed deadline.
